ASME Standard T50 40 Ft LPG Storage Tank Manufacturers

ASME Standard T50 40 Ft LPG Storage Tank Manufacturers
ASME Standard T50 40 Ft LPG Storage Tank Manufacturers ASME Standard T50 40 Ft LPG Storage Tank Manufacturers ASME Standard T50 40 Ft LPG Storage Tank Manufacturers ASME Standard T50 40 Ft LPG Storage Tank Manufacturers

Großes Bild :  ASME Standard T50 40 Ft LPG Storage Tank Manufacturers

Produktdetails:
Place of Origin: CHINA
Markenname: GNEE
Zertifizierung: SGS
Zahlung und Versand AGB:
Minimum Order Quantity: ≥1sets
Packaging Details: wooden box
Payment Terms: MoneyGram,Western Union,T/T,D/P,D/A,L/C
Supply Ability: Annual Production 30,000 tons
Kontakt

ASME Standard T50 40 Ft LPG Storage Tank Manufacturers

Beschreibung
Condition: New Design Code: ASME
Fluid: LNG, LOX, LIN, LAR, LCO2, etc. Machinery Test Report: Provided
Max Working Pressure: 2.16mpa Size: customizable
Safety Devices: Pressure Relief Valve, Level Gauge, Thermometer Form: Large sized
Durable Years: 20 years Outer Vessel Material: Carbon Steel
Hervorheben:

ASME Standard LPG storage tank

,

40 ft LPG gas tank

,

T50 LPG storage tank manufacturers

ASME Standard T50 40 Ft LPG Storage Tank Manufacturers
Product Specifications
Attribute Value
Condition New
Design Code ASME
Fluid LNG, LOX, LIN, LAR, LCO2, etc.
Machinery Test Report Provided
Max Working Pressure 2.16mpa
Size Customizable
Safety Devices Pressure Relief Valve, Level Gauge, Thermometer
Form Large sized
Durable Years 20 years
Outer Vessel Material Carbon Steel
Product Description

An LPG storage tank is a full-pressure stationary pressure vessel with a single-layer tank structure, which is dedicated to storing liquefied petroleum gas. The tanks use low-alloy steel plates, which have excellent performance, safety, and reliability.

Technical Parameters
Nominal Volume Effective Volume Maximum Filling Volume Daily Evaporation Rate(N) Maximum working pressure Outer Diameter Total Height Empty Weight
10,523 L 10,000 L 8,100 kg
11,410 kg
13,930 kg		 0.495 daily 0.8 Mpa 2,300 mm 5,850 mm 6,280 kg
10,523 L 10,000 L 8,100 kg
11,410 kg
13,930 kg		 0.495 daily 1.6 Mpa 2,300 mm 5,850 mm 7,250 kg
21,000 L 20,000 L 16,200 kg
22,820 kg
27,860 kg		 0.45 daily 0.8 Mpa 2,600 mm 7,880 mm 9,850 kg
21,000 L 20,000 L 16,200 kg
22,820 kg
27,860 kg		 0.45 daily 1.6 Mpa 2,600 mm 7,880 mm 12,335 kg
31,600 L 30,000 L 24,316 kg
34,255 kg
41,820 kg		 0.396 daily 0.8 Mpa 2,600 mm 10,820 mm 14,625 kg
31,600 L 30,000 L 24,316 kg
34,255 kg
41,820 kg		 0.396 daily 1.6 Mpa 2,600 mm 10,820 mm 14,625 kg
52,600 L 50,000 L 40,500 kg
57,050 kg
69,650 kg		 0.315 daily 0.8 Mpa 3,000 mm 12,590 mm 21,550 kg
52,600 L 50,000 L 40,500 kg
57,050 kg
69,650 kg		 0.315 daily 1.6 Mpa 3,000 mm 12,590 mm 26,000 kg
106,200 L 100,000 L 81,000 kg
114,100 kg
139,300 kg		 0.245 daily 0.8 Mpa 3,400 mm 19,500 mm 45,000 kg
106,200 L 100,000 L 81,000 kg
114,100 kg
139,300 kg		 0.245 daily 1.6 Mpa 3,400 mm 19,500 mm 54,000 kg
Capacity of LPG Tank 5m3
Orientation of LPG Tank Horizontal Single Layer LPG TANK
Design Pressure 1.77MPa
Working Pressure 1.63MPa
Working Temperature -19~50℃
Medium LPG (Propane)
Heat Treatment Post-weld heat treatment for LPG Tank
ASME Standard T50 40 Ft LPG Storage Tank Manufacturers 0 ASME Standard T50 40 Ft LPG Storage Tank Manufacturers 1 ASME Standard T50 40 Ft LPG Storage Tank Manufacturers 2
Product Features
  • Types: liquid oxygen tank, liquid nitrogen tank, liquid argon tank, liquid Nitrous Oxide tank, liquid carbon dioxide tank, LNG tank
  • Tank capacity: 2 m³~350 m³
  • Tank pressure: 8 bar, 16 bar, or based on user requirement
  • Tank product certificate: GB, ASME
  • Type: Vertical/Horizontal

Our company is a professional manufactory of large storage tanks, it contains the design, provided steel material and overseas installation. Professional engineers and construction teams, all the tanks are made in accordance with international standards.

The large storage tanks of various specifications and models can be made. We can choose different types and different materials storage tanks according to the properties of the materials.

If you want to learn more about our products, you can send an email to info@gneeheatex.com. We are more than happy to assist you.
